Engineered three-layer composite containment system designed for petrochemical refineries, thermal power plants, cement manufacturing towers, and heavy structural steel erection. Certified to IS 11057:1984 and EN 1263-1 Class B2 (> 4.4 kJ rating).
Heavy-duty 100mm structural fall net + 1mm fine debris net + flame-retardant thermal barrier overlay.
Certified for extreme chemical resistance and high-elevation industrial maintenance.
Unlike standard single-layer construction nets, the GCM Triple-Layer Refinery Net combines three integrated polymer layers into a unified heavy-duty composite panel, stitched with high-tenacity UV-stabilized polyolefin thread:
Specification: 100mm × 100mm or 60mm × 60mm square mesh constructed from Ø 5.0mm / 6.0mm braided High-Tenacity PPMF/Nylon core with > 4.2 kN twine breaking force. Designed to arrest falling personnel with dynamic energy absorption > 4.4 kJ (EN 1263-1 Class B2).
Specification: 25mm × 25mm diamond mesh HDPE 15-ply / 2.5mm braided net. Captures dropped tools, nuts, bolts, scaffolding couplers, and masonry fragments falling from height.
Specification: 100 GSM – 150 GSM high-density monofilament mesh (< 1mm aperture). Prevents fine gravel, sand, cement dust, and light welding spatter from raining down onto personnel or sensitive machinery below.
| Parameter | Engineering Value | Compliance Standard |
|---|---|---|
| Perimeter Border Rope | Ø 12mm - Ø 14mm (30.0 kN / 35.0 kN) | IS 14929:2022 / EN 1263-1 |
| Energy Absorption | Class B2 (> 4.4 kJ) / Class A2 (> 2.3 kJ) | EN 1263-1 System S |
| Dynamic Drop Test | 100 kg Sandbag @ 6.0m Free Fall | IS 11057:1984 Passed |
| UV Stabilization | HALS + Furnace Carbon Black (500 kly) | 5-to-7 Year Operational Life |
| Standard Panel Sizes | 10m × 5m, 6m × 4m, 5m × 3m, Custom | Rigging Ready with Tie Cords |
Direct factory wholesale supply · Free on-site laser survey · 5-year replacement guarantee
